Flowline LC4 / LC9 Series Switch Pro Remote Level Controller

The Flowline LC4 / LC9 Series Remote Level Controller is available in CSA approved, general purpose (LC4X)or isolation (LC9X) with
built-in intrinsic safety barriers for use with associated apparatus, the level controller is offered in three configurations
for pump and valve control. The LC40/90 accepts one level sensor input and provides one 10A relay. The LC41 accepts two
level sensor inputs and provides one latching 10A relay for automatic fill or empty control. The LC42/92 accepts three
level sensor inputs with one latching 10A relay output for automatic fill or empty control, and a second non-latching
10A relay for high level alarm or low level alarm. For field mount installation, add a single or dual indicator NEMAbox. Additional features of the Flowline LC4 / LC9 Series Switch-Pro Remote Level Controller include:
